| Model No. |
PT-LW375 |
PT-LW335 |
| Power supply |
AC100–240 V 1.5A–3.5A 50 Hz/60 Hz |
AC100–240 V 1.5A–3.5A 50 Hz/60 Hz |
| Power Consumption |
300W
6W when Standby mode set to Normal,
0.5W when Standby mode set to Eco* |
300W
6W when Standby mode set to Normal,
0.5W when Standby mode set to Eco* |
| LCD Panel |
15.0 mm (0.59 inches) diagonal |
15.0 mm (0.59 inches) diagonal |
| LCD Panel Aspect Ratio |
16:10 |
16:10 |
| Lamp |
230 W UHM lamp |
230 W UHM lamp |
| Brightness |
3,600 lumens (lamp power: normal) |
3,100 lumens (lamp power: normal) |
| Lens (Throw ratio) |
1.48– 1.78:1 |
Manual zoom (1.2×), manual focus F 2.1– 2.25, f 19.11– 22.94 mm |
| Contrast (Full on/full off) |
16,000:1 (all white/all black, Image mode: Dynamic,
Lamp control: Normal, Iris: On) |
16,000:1 (all white/all black, Image mode: Dynamic,
Lamp control: Normal, Iris: On) |
| Resolution Native/maximum*1 |
1,280 × 800 pixels (Input signals that exceed this resolution will be converted to 1,280 × 800 pixels.) |
1,280 × 800 pixels (Input signals that exceed this resolution will be
converted to 1,280 × 800 pixels.) |
| Screen Size |
30–300 inches (0.76 –7.62 m) diagonally, 16:10 aspect ratio |
30–300 inches (0.76 –7.62 m) diagonally, 16:10 aspect ratio |
| Optical Axis Shift |
13:1(fi xed) |
13:1(fi xed) |
| Keystone Correction Range |
Vertical: ±30°, horizontal: ±15° |
Vertical: ±30°, horizontal: ±15° |
| Dimensions(W x H x D) |
44 × 105 × 20.5 mm
(1-23/32 × 4-1/8 × 13/16 inches) |
335 × 96* 4 × 252 mm
(13-3/16 × 3-25/32*4 × 9-29/32 inches) |
| Weight |
Approx. 63 g (2.22 oz) (including batteries) |
Approx. 2.9 kg (6.4 lbs) |
