• High quality image with 4MP, 1/1.8” CMOS sensor
• 2688 × 1520@60 fps in the main stream, offering smoother live video and more details
• Ultra 265, H.265, H.264, MJPEG
• Wise-ISP technology, comprehensive improvement in image quality
• Metadata analyse, supports human body, motor vehicle and non-motor vehicle image capture and attribute collection, realizes data visualization management, allows users to get target information for further data analysis
• , supports front-end comparison, supports blocklist and allowlist comparison, increases the concurrent detection number up to 120
• Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection
• People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios
• LightHunter technology ensures ultra high image quality in low illumination environment
• Up to 140 dB optical WDR (Wide Dynamic Range)
• DC 12 V or PoE (IEEE 802.3af) power supply
• Wide voltage range of ±25% in DC
Built with excellence, delivered with trust.
Your happiness is our highest success.
Crafted to meet industry standards with perfection.
| IPC3234EA-AHDZK-I1 | IPC3234EA-AHDX4K-I1 | |||||||
| Camera | ||||||||
| Sensor | 1/1.8″ CMOS | |||||||
| Min. Illumination | Colour:0.0003 lux (F1.2, AGC ON) B/W:0.0001 lux (F1.2, AGC ON) 0 lux with IR | Colour:0.0005 lux (F1.6, AGC ON) B/W:0.0003 lux (F1.6, AGC ON) 0 lux with IR | ||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||
| Shutter | Auto/Manual, 1 to 1/100000 s | |||||||
| WDR | 140 dB | |||||||
| S/N | >56 dB | |||||||
| Lens | ||||||||
| Focal Length | 2.8 to 12 mm | 8 to 32 mm | ||||||
| Optical Zoom | 4X | |||||||
| Iris | F1.2 | F1.6 | ||||||
| Field of View (H) | 106.6°~ 51.3° | 42.6°~ 15.2° | ||||||
| Field of View (V) | 56.9°~ 28.6° | 23.5°~ 8.9° | ||||||
| Field of View (D) | 131.1°~ 63.1° | 52.4°~ 17.9° | ||||||
| Iris Type | P-iris | |||||||
| DORI | ||||||||
| DORI Distance (Detect) | 68.0m(223.0ft)~166.2m(545.2ft) | 124.1m(407.3ft)~496.6m(1629.1ft) | ||||||
| DORI Distance (Observe) | 27.2m(89.2ft)~66.5m(218.1ft) | 49.7m(162.9ft)~198.6m(651.6ft) | ||||||
| DORI Distance (Recognize) | 13.6m(44.6ft)~33.2m(109.0ft) | 24.8m(81.5ft)~99.3m(325.8ft) | ||||||
| DORI Distance (Identify) | 6.8m(22.3ft)~16.6m(54.5ft) | 12.4m(40.7ft)~49.7m(162.9ft) | ||||||
| Illuminator | ||||||||
| Illumination Distance (IR) | 40 m (131.2 ft) | |||||||
| Wavelength | 850 nm | |||||||
| IR On/Off Control | Auto/Manual | |||||||
| Video | ||||||||
| Frame Rate-Main Stream | 4MP(2688*1520), Max 60fps | |||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||||
| Frame Rate-Sub Stream | 2MP(1920*1080), Max 60fps | |||||||
| Video Bit Rate | 128 Kbps to 16 Mbps | |||||||
| ROI | Support | |||||||
| Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) | |||||||
| Video Stream | Triple streams | |||||||
| OSD | Up to 10 OSDs | |||||||
| Frame Rate-Third Stream | D1 (720*576), Max 60fps | |||||||
| Image | ||||||||
| White Balance | Auto&Outdoor&Fine Tune&Sodium Lamp&Locked&Auto2 | |||||||
| Digital Noise Reduction | 2D/3D DNR | |||||||
| Smart IR | Support | |||||||
| Flip | Normal&Flip Vertical&Flip Horizontal&180°&90°Clockwise&90°Anti-clockwise | |||||||
| HLC | Support | |||||||
| Defog | Digital defog | |||||||
| Intelligent | ||||||||
| Metadata Analyse | Support human body, motor vehicle and non-motor vehicle image capture and attribute collection | |||||||
| Recognition | ||||||||
| People Counting | Support people flow counting and crowd density monitoring | |||||||
| Exception Detection | Object removed, Object Left Behind, Scene change, Defocus detection | Object removed, Object Left Behind | ||||||
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) | |||||||
| Events | ||||||||
| Basic Detection | Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change, Defocus detection | Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind | ||||||
| General Function | Watermark&IP Address Filtering&Access Policy&ARP Protection&RTSP Authentication&User Authentication&HTTP authentication&Alarm input&Alarm output | |||||||
| Audio | ||||||||
| Audio Compression | G.711U&G.711A | |||||||
| Audio Bitrate | 128 Kbps | |||||||
| Two-way Audio | Support | |||||||
| Suppression | Support | |||||||
| Sampling Rate | 16KHZ | |||||||
| Storage | ||||||||
| Edge Storage | Micro SD, up to 512 GB | |||||||
| Network Storage | ANR&NAS(NFS) | |||||||
| Network | ||||||||
| Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3 | |||||||
| Compatible Integration | API, SDK, ONVIF (Profile S, Profile G, Profile T, Profile M) | |||||||
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator | |||||||
| Security | Password protection&Strong password&HTTPS encryption&Export operation logs&Basic and digest authentication for RTSP&Digest authentication for HTTP&TLS 1.2&WSSE and digest authentication for ONVIF | |||||||
| Client | EZStation, UNV-Link, UNV-Link Pro | |||||||
| Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above&Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above | |||||||
| Interface | ||||||||
| Audio I/O | 2 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] | |||||||
| Alarm I/O | 3/2 | |||||||
| Serial Port | 1 channel RS485 interface | |||||||
| Built-in Mic | Support, built-in mic*2 | |||||||
| Built-in Speaker | Support | |||||||
| Network | 1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet | |||||||
| Certification | ||||||||
| EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) | |||||||
| Safety | CE LVD (EN 62368-1:2014+A11:2017) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) | |||||||
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) | |||||||
| Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) | |||||||
| General | ||||||||
| Power | DC12V(±25%) , PoE+ (IEEE 802.3af) | |||||||
| Power Consumption | 17W | 18W | ||||||
| Power Interface | Ø5.5 mm coaxial power plug | |||||||
| Dimensions | Ø 148.0 x 111.4 mm (Ø 5.8” x 4.4”) (Ø x H) | |||||||
| Built-in DC12V Output | Support | |||||||
| Weight | 1.01kg(2.23lb) | 1.06kg(2.34lb) | ||||||
| Working Environment | -30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||
| Surge Protection | 6 KV | |||||||
| Reset Button | Support | |||||||
| Heater | Support | |||||||
| Brand | UNV |
|---|
